OEM manufacturing support for axial flux permanent magnet motor programs from design review to prototype, pilot build, and repeat production.
| Program Metric | Typical Range | Procurement Value |
|---|---|---|
| RFQ completeness | Drawing plus target map preferred | AFPM quotes are unreliable without package, voltage, torque-speed, thermal, and inspection assumptions. |
| Revision control | Lot and drawing based | Fast AFPM iteration requires clear data ownership or test results become ambiguous. |
| Prototype gate coverage | DFM, dimensional, electrical, thermal, and balance evidence | A sample is useful only when it closes the risks that block pilot approval. |
| Outgoing record set | Buyer CTQ and lot-control dependent | Repeat production needs consistent evidence, not one-off prototype communication. |
OEM capability pages should make supplier qualification easier. Use this flow to align design responsibility, process checkpoints, outgoing records, and change control before samples move into pilot supply.
| Gate | Control Focus | Record / Output |
|---|---|---|
| Scope freeze | Design ownership model: build-to-print, co-design, or clean-sheet target; Drawing package, BOM, CTQ list, prototype quantity, and target lead time | Quotation boundary, drawing revision, CTQ list, sample quantity, and test responsibility. |
| Process control | Design freeze, drawing revision control, BOM risk, and CTQ alignment; Assembly fixture strategy for airgap, magnet handling, and rotor balance | Material route, fixture plan, in-process checks, and supplier risk log. |
| Outgoing evidence | RFQ completeness, Revision control, Prototype gate coverage, Outgoing record set | Inspection report, electrical screen, mechanical screen, balance or thermal notes, and lot labels. |
| Repeat supply | Freeze the first quotation boundary: components only, subassembly, or complete motor.; Define production-intent materials, fixtures, and inspection records early.; Use drawing revision, effective lot, supplier change notice, and revalidation rules for every material or process change. | Effective-lot change control, corrective action loop, packaging standard, and shipment milestone plan. |
Yes for early feasibility, but formal quotation needs package envelope, voltage, cooling, and acceptance criteria.
An actionable RFQ defines supply form, torque-speed duty, voltage/current limits, package envelope, cooling, CTQ records, quantity plan, and ownership of design changes.
The practical control is to freeze revision, BOM, material substitutions, inspection method, and outgoing record format before pilot release.
Inquiry Email
Please include application, peak/continuous torque, speed range, voltage/current limit, outer diameter, axial length, cooling method, quantity, and drawings or reference samples.
